Services · 02

Design and
drawings.

Kitchen and furniture drawings from a 3D model: layouts, elevations, services set-out and photoreal renders, revised to the architect's comments.

See the drawings

Drawn to be built.

We draw what we are instructed to draw, to the architect's layouts and the manufacturer's specification.

01

Layouts & elevations.

Open drawing
Full kitchen drawing sheet: front and side elevations, plan, unit schedule, isometric, notes and the Spektra title block, with the client and project details blurred
  1. 02

    Services set-out.

    Full socket, services and recess set-out sheet for M&E coordination, with the Spektra title block and the client and project details blurred

    Socket, services and recess set-out for M&E coordination.

  2. 03

    Photoreal renders.

    Kitchen rendered from the 3D model: dark grey slab doors, an oak-effect worktop and upstand, a white sink and tap

    See the kitchen render before anything is ordered.

Beyond the kitchen.

Drawings for fitted and loose furniture, from the same 3D model.

  1. 04

    Furniture drawings.

    Dining table drawing sheet: side and end elevations, plan on the top, 3D view, notes and the Spektra title block, with the client blurred

    Detailed drawings for loose and fitted furniture, from tables to media units, ready for the manufacturer.

  2. 05

    3D model.

    Dining table with a quartz top and a brass-finish welded base, rendered from the 3D model in a room setting

    Every piece modelled in 3D first, so the drawings and renders agree.

Every drawing is issued for your comments, revised and signed off, with each revision on record. Our design work is covered by professional indemnity insurance.

Once signed off, the drawings carry straight into procurement.

Send us your project details.

Drawings, programme, site address and unit count. We’ll come back with a proposal.
